Gymnasium Multi-level Parking Project

Project Overview

Project Name

Gymnasium Multi-level Parking Project

Country

China

City

 Jianshui

Application

Gymnasium

System Type

Traditional planar movement

Total Parking Spaces

519

Floors

8 (Parking floors 4-8)

User operation method

LCD panel, Button/IC card

Project duration

2021.03.17-2021.06.14 (60 days, excluding acceptance inspection)

Special Features

Integrated operation of shopping mall and parking lot

Technical Specs

Vehicle Size

5300×1900×1550，308 sedans；5300×1900×1900，206 SUVs
4700×1800×1450，5 sedans

Max Vehicle Weight

2350 kg

Retrieval Time

60m /minutes

Automation Level

Semi-automatic

Structure

Steel structure

Certifications

CE / ISO / SGS

Site Conditions

Clear Height

37.9 meters

Footprint

2489.76㎡ (136.8m x 18.2m)

Onground/Underground/Both

Onground

Civil Constraints

Seismic resistance, waterproofing, foundation bearing capacity,high temperatures, hot and humid conditions,fire resistance
